Poly Crystalline

Need a material that stays strong, stays clear, and stays cool under extreme conditions? Polycrystalline CVD diamond is built for that.

At IMAT, we grow polycrystalline diamond in our own CVD reactors. You get self-standing disks up to Ø75 mm, from 0.3 mm to 7 mm thick, finished to the surface quality your project needs.

Poly Crystalline.

What Is Poly Crystalline Diamond?

Polycrystalline diamond is real diamond, made in a lab. In the CVD (chemical vapor deposition) process, carbon from a gas settles onto a base layer, building it up layer by layer. Over many hours, it grows into a solid diamond plate.

The word “poly” means many. The plate is made of many tiny diamond grains joined together. This is why polycrystalline diamond can be grown in large sizes, which is hard to do with single-crystal diamond. It also costs less per area.

Not sure which one you need? See our mono / single crystalline diamond page to compare.

Why Choose Polycrystalline CVD Diamond?

  • Excellent heat spreading. Diamond moves heat faster than any other bulk material at room temperature. It keeps lasers, chips, and sensors cooler.
  • Extreme hardness. It resists scratches, wear, and sand-like particles. Parts last longer.
  • Clear over a wide range of light. Optical-grade diamond lets light pass from ultraviolet through infrared, and even microwaves and terahertz.
  • Tough in harsh places. It resists acids, high heat, and strong radiation.
  • Low thermal expansion. It does not swell much when it gets hot, so your parts stay in shape.

Choose the Right Grade

Every project is different. Pick the grade that fits your job.

  • Optical grade: Very clear, with low light loss. Best for laser windows, ATR windows, and optical windows.
  • Thermal grade: Built to move heat away fast. Best for heat spreaders and heat sinks for lasers, RF devices, and power electronics.
  • Mechanical grade: Made for strength and wear resistance. Best for cutting tools, wear parts, and anvils.
  • Electronic grade: High purity with low electrical noise. Best for radiation detectors and sensors.

IMAT’s Polycrystalline CVD Diamonds deliver excellent strength, durability, and thermal stability for demanding industrial and electronic applications. Available in customized sizes, thicknesses, and surface finishes, they offer versatile material solutions. With high purity and reliable performance, they are ideal for advanced engineering, semiconductor, and optical technologies. Choose IMAT for precision-engineered polycrystalline diamond solutions tailored to your application requirements.

Specification Details
Size Up to Ø75 mm
Thickness 0.3 mm to 7 mm
Grade Electronic, Optical, Thermal, Mechanical
Surface
  • As Grown
  • Polished (Ra < 3 nm, Flatness < 1 fringes @ 633 nm)
  • Flatness (Power < 2 fringes @ 633nm, Irregularity < 1 fringes @ 633nm over Ø75mm)
  • Lapped (Ra< 200nm, Flatness < 1 fringes @ 633nm)
  • Parallelism, Wedged
Type/Orientation
  • Coating on Various Substrates)
  • Self standing Disks
  • Customized shapes such as rectangle rods
  • AR coated windows
Edges Laser cut
Name

Frequently Asked Questions

Q.1 What is poly crystalline CVD diamond?

It is lab-grown diamond made of many small diamond grains. It is grown from gas using chemical vapor deposition and cut into disks, windows and custom parts.

Single crystal diamond is one continuous crystal. Polycrystalline diamond is made of many grains. This lets us make much larger plates at a lower cost per area. Single crystal is chosen when the highest purity or crystal perfection is needed.

Yes. It is true diamond, so it has the same carbon structure and the same extreme hardness.

Yes, IMAT provides standard and customised CVD diamond solutions with different sizes, shapes, and polishing options to meet specific application requirements.

Up to Ø75 mm and from 0.3 mm to 7 mm thick. Custom shapes are possible.

Up to Ø75 mm and from 0.3 mm to 7 mm thick. Custom shapes are possible.
